  • Granulating machines, mixing machines, drying machines, tablet presses, encapsulating machines, punches and dies, packaging machines, and other ancillary machines are just some of the pharmaceutical machines needed to turn powder into pills. It is important to find the best Tablet Dies manufacturer for the same.

    Compression tools, tablet tools, and tablet punches and dies are all names for the same thing. High-quality tablet tools can provide superior performance, high productivity, and extended tool life. Each batch of tablets is standardized in size, shape, imprint, and weight with the help of a dedicated tablet tool.

    No image found
    No image found

    The tablet press machine, whether a single-punch tablet press machine or a rotary press machine, is equipped with the necessary die and punches. Granulated material is measured into a cavity formed by a lower punch, an upper punch, and a die to create a tablet from powder. After that, the punches are pressed together to squeeze the material in the center die. The materials in the middle die are compressed thanks to the external pressure of the up punch and the down punch.

    The shape of a tablet is created by pressing two punches together and then using a die to cut out the desired shape.

    Step 1:

    The bottom punch is lowered into the die to feed the granulated feedstock into the die, creating a cavity.

    Step 2:

    It is possible to regulate precisely the quantity of powder introduced into the cavity by adjusting the depth to which the lower punch penetrates.

    Step 3:

    The overhang is removed by scraping, and the lower punch is temporarily covered while being drawn down to prevent spillage.

    Step 4:

    As the lid is pried off, the upper punch is lowered to make contact with the powder.

    Step 5:

    High-pressure compression rolls apply the necessary force to compact the coarse material into a compact tablet.

    Step 6:

    The tablet is expelled by raising the lower punch following compression.
